We are the leading company for manufacturer, exporter and supplier of elevated range of Geared Monorail Travelling Trolley. The offered Geared Monorail Travelling Trolley is manufactured with the help of high class material and sophisticated technology, in compliance with set industrial norms. This trolley is applicable in various heavy duty industries for supporting transport work. Clients can avail this Geared Monorail Travelling Trolley from us as per their necessities at market leading prices in various specifications.
Geared Monorail Travelling Trolley
Dimensions, Weight and Performance Data
Push
500
Push/Geared
Geared
Geared
Capacity
kg
1000
3000
5000
10,000
Inside of wheel flanges mm
Range 1
50-130
58-150
90-160
110-150
140-170
Range 2
140-200
150-210
160-220
160-210
180-210
Range 3
210-305
210-305
220-305
215-265
215-245
A Seat of susp, plate to runner tread
Range 1 & 2 mm
75
89
110
84
137
Range 3 mm
115
129
155
B runner tread diameter
mm
50
65
90
175
225
C runner tread width
mm
20
25
30
45
50
D runner centres
push mm
70
90
125
-
-
Geared mm
-
128
157
253
313
E underside of runner to suspension plate
mm
18
28
28
-
-
F underside of runners to top of hand chain wheel, geared travel only
mm
101
106
123
-
-
G beam flange to shaft end
mm
-
124
124
180
275
H overall width, push travel only
Range 1 mm
210
248
276
-
-
Range 2 mm
320
320
340
Range 3 mm
410
410
425
J Crossbolt to track centreline on ungeared side (geared trolleys only)
Range 1
track widths J mm
-
58-100
100-126
170
210
132
152
track widths J mm
-
100-140
126-153
120
134
Range 2
track widths J mm
-
140-156
153-192
200
225
164
184
track widths J mm
-
166-210
192-216
152
166
Range 3
track widths J mm
-
210-263
216-263
225
240
238
205
track widths J mm
-
263-305
263-305
205
213
K depth of plateRange 1, 2 & 3 mm
21
21
34
-
-
L overall length
(Push) mm
160
200
275
-
-
(geared) mm
238
290
550
690
M underside of runner to flange (Push) mm
60
75
105
-
-
N underside of runner to gear tip (geared) mm
-
90
115
-
-
Minimum rados of track curve mm
(Push)
1250
1500
1500
-
-
(geared)
-
1500
1500
2600
3200
Push travel weight in Kg.
Range 1
4.0
10.5
18.5
-
-
Range 2
4.5
11.0
20.0
Range 3
6.5
14.5
25.5
Geared travel weight in kg
Range 1
-
11.5
20.0
70
151
Range 2
-
12.5
21.5
72
153
Range 3
-
16.0
17.0
75
155
Nominal 1.5 mm clearance to be allowed from edge of track flange to inside of wheel flange (3 mm overall on both side)
Overall width of geared travel trolleys - J + (1/2 x track width) + G. On 500 to 2500 Kg. units when using the narrower track widths the cross bolt adjusting washers are to be assembled such that the end of the cross bolt is clear of the hand chain wheel.
Weight of trolleys only exclude hand chain. Hand chain is 0.45Kg/m per linear length up to and including 2t capacity.
Bottom of hand chain loop is 460 mm from ground level.
